Accuracy: ± 2.3 %
Approvals: Class I, II, III, Div. 1,Groups C, D, E, F and G
Impedance: 280 Ω
Linearity: <2.0% of span
Materials: Epoxy, Die-Cast Zinc
Hysteresis: <1.0% of span
Input Current: 4 to 20 mA
Input Voltage: N/A
Pressure Type: Gauge
Repeatability: <0.5% of span
Enclosure Type: N/A
Flow Rate Note: 20 scfm @ 150 psig
Input Resistance: <300 Ω
Enclosure Ratings: IP65, NEMA Type 4
Media Compatibility: Clean Dry Air
Input Control Signal: N/A
Output Pressure, Max: 120 psi
Output Pressure, Min: 3 psi
Supply Pressure, Max: 150 psi
Electrical Connection: 1/2 in NPT Female Conduit
Total Air Consumption: 1.8 SCFH
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Air Supply Pressure, Max: 150 psi
Air Supply Pressure, Min: 125 psi
Volumetric Flow Rate, Max: 20 SCFM
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -29 °C
Supply Pressure Sensitivity: ±0.004% span per 1.0 psig
Material Construction Option: N/A
