Approvals: CE, RoHS, UKCA
Materials: Aluminum, 316 Stainless Steel
Vibration: 350 to 370 Hz
Time Delay: 1 to 3 sec
Sensitivity: Switch selectable - HI/LO
Switch Type: SPDT NO/NC, Selectable
Density, Max: 0.7g/cm ³
Probe Length: 4 in
Switch Rating: 5 A @ 250Vac/28Vdc
Supply Voltage: 20 to 250 Vac/Vdc
Enclosure Ratings: IP65
Materials, Wetted: 316 Stainless Steel
Power Consumption: 10 VA
Supply Power Type: AC/DC
Media Compatibility: Oil, Solvents, Water
Electrical Connection: 1/2 in NPT female Conduit with Screw Terminal block
Operating Pressure, Max: 600 psi
Process Connection Size: 1 in
Process Connection Type: NPT Male
Process Temperature, Max: 130 °C
Process Temperature, Min: -40 °C
Vertical Load on Rod, Max: 20 Nm
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -40 °C
