Approvals: CSA(US) CSA(C), CE
Materials: Powder Coated Aluminum
Stability: ± 0.027 pf per °C @ 0.5 pf setting
Insulation: PVC
Time Delay: 0.25 to 15 sec
Sensitivity: 0.5 pf to 150 pf
Switch Type: SPDT NO/NC, Selectable
Altitude,Max: 2000 m
Probe Length: 16 in
Switch Rating: 5 A @ 250 Vac, 30 Vdc
Supply Voltage: 115 Vac, 2.5 VA
Dielectric Range: 1.5 to 9.0
Sensitivity Note: Multi-turn potentiometer adjustment 0.5 pf to 150 pf
Enclosure Ratings: IP66, NEMA Type 4
Materials, Wetted: 316 Stainless Steel, Aluminum, Nylon
Supply Power Note: 115 Vac (± 15%), 2.5 VA, 50/60 Hz
Supply Power Type: AC
Media Compatibility: Air, Alkaline solutions, Argon, Carbon dioxide, Dilute Acids, Gases, Helium, Hydraulic Oil, Hydrogen, Light Oil, Liquids, Nitrogen, Non-Corrosive Dry Gases, Oil, Oxygen, Solvents, Steam, Water, Water-based fluids
Electrical Connection: 3/4 in NPT female Conduit with Screw Terminal block
Operating Pressure Note: 3.5 bar (50 psi) maximum (aluminum connection)
Operating Pressure, Max: 50 psi
Process Connection Size: 1 1/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 65 °C
Operating Temperature, Min: -40 °C
Material Construction Option: Aluminum, Food Grade Nylon
