Accuracy: ± 0.04 inH2O
Approvals: CE, RoHS
Insulation: PVC
Wire Gauge: 22 AWG
Switch Type: SPST
Cable Length: 10 ft
Probe Length: 5 in
Repeatability: ± 0.02 inH2O
Switch Rating: 1 A @ 60 or 120 Vac/Vdc
Probe Diameter: 0.75 in
Supply Voltage: 12 to 36 Vdc
Immersion Depth: 2.6 in
Number of Wires: 4
Conductive Range: > 100 µS/cm
Dielectric Range: >20 constants
Switch Operation: Selectable Normally Open or Normally Closed
Enclosure Ratings: IP66, NEMA Type 4
Materials, Wetted: Polypropylene
Power Consumption: 25 mA
Supply Power Type: DC
Media Compatibility: Oil, Solvents, Water
Operating Pressure Note: 150 psi @ 25°C (76°F), derated @ 1.667 psi per °C above 25°C (76°F)
Operating Pressure, Max: 150 psi
Process Connection Size: 3/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 90 °C
Operating Temperature, Min: -40 °C
