Shock: 100g (980 m/s²)
Switch: Dual
Weight: 80 g
Display: LED Display
Accuracy: ± 1 %
Deadband: 0 to 150 psi
Materials: ABS, Zinc Alloy
Vibration: 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude
Switch Type: PNP
Accuracy Note: ± 1% FS
Deadband Type: Adjustable
Output Detail: 0 to 5 Vdc, 2 PNP
Output Signal: Voltage
Pressure Type: Gauge
Pressure, Max: 150 psi
Pressure, Min: 0 psi
Repeatability: ± 1%
Response Time: 135 ms
Burst Pressure: 300 psi Maximum
Control Output: PNP
Number of Digits: 4
Acceleration, Max: 10g (98 m/s²)
Supply Power Note: Current Consumption ≤80 mA
Repeatability Note: ± 1% FS
Media Compatibility: Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen
Temperature Accuracy: ± 2 °C
Electrical Connection: Cable
Setpoint Repeatability: ± 1% FS
Process Connection Size: 1/8 in
Process Connection Type: BSPT Male
Process Temperature, Max: 100 °C
Process Temperature, Min: 0 °C
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -20 °C
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -10 °C
Operating and Storage Humidity: 35 to 85% RH
