Shock: 50 g, 11 ms half sine
Weight: 150 g
Accuracy: ± 0.25 %
Bandwidth: DC to 1 kHz
Stability: ± 0.25%
Vibration: ± 20 g
Cable Length: 1.5 m
Accuracy Note: Static Accuracy 350 mB to 700 bar: ± 0.25% FS BSL at 25ºC (includes linearity, hysteresis and repeatability)
Output Signal: Voltage
Pressure Type: Compound Gauge
Pressure, Max: 1 bar
Pressure, Min: -1 bar
Response Time: 1 ms
Accuracy Class: 0.1% to 0.25%
Stability Note: Long Term Stability (1 yr): ± 0.25% FS
Supply Voltage: 15 to 30 Vdc
Pressure Cycles: 10 million
Electrical Output: 0 to 10 V
Enclosure Ratings: IP65
Materials, Wetted: None
Supply Power Note: 15 to 30 Vdc at 10 mA
Burst Pressure Note: None
Electrical Connection: Cable
Insulation Resistance: 1 MΩ
Electrical Output Note: None
Process Connection Size: 1/4 in
Process Connection Type: BSPP Male
Electrical Connection Note: 1.5 m (5') 2 or 3-conductor cable, mA or 10V outputs, respectively.
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -40 °C
Compensated Temperature, Max: 85 °C
Compensated Temperature, Min: -20 °C
Thermal Effect on Span error, Max: ± 1% absolute
Thermal Effect on Zero error, Max: ± 1% absolute
