Mounting: Any (preferably with solenoid system upright)
Cv Factor: 9 gal/min
Materials: 316 Stainless Steel, PTFE, Stainless Steel 300, Stainless Steel 400, Gold-Plated Copper
Coil Power: 8 W
Duty Cycle: 100%
Media Type: N/A
Valve Type: Pilot Operated
Cycling Rate: 1000 cpm
Orifice Size: 1 in
Valve Position: Normally Closed
Enclosure Ratings: NEMA Type 4
Materials, Wetted: 316 Stainless Steel, Copper, PTFE, Stainless Steel
Voltage Tolerance: ±10%
Open Response Time: 100 to 200 ms
Close Response Time: 200 to 1200 ms
Media Compatibility: Hot Water, Steam
Coil Molding Material: Black Polyphenylensulphide (Class H): SV8COIL-115/60 HZ, SV8COIL-220/60 HZ Black Epoxy Resin (Class H): All 14 W coils, NEMA 4
Operating Pressure Note: AC 150 psi, DC 150 psi
Operating Pressure, Max: 150 psi
Operating Pressure, Min: 7 psi
Process Connection Size: 1 in
Process Connection Type: NPT Male
Process Temperature, Max: 182 °C
Process Temperature, Min: 60 °C
