Height: 21 mm
Weight: 31 g
Accuracy: ± 5 µA
Diameter: 43 mm
Approvals: BS EN 61326 ; 1998 – Electrical equipment for measurement and control ANNEX A ; ANNEX F
Isolation: Galvanic Isolatiion, 250 Vdc
Stability: Offset: 0.1°C/°C;Span: 0.05°C/°C
Input Type: Thermocouple, Voltage
Calibration: Pushbutton
Output Load: [(Vsupply-10)/20] kΩ
Sensor Type: Transmitter
Probe Length: 0 mm
Warm Up Time: 1 min to full accuracy
Accuracy Note: (mA output/2000) or 5 uA (whichever is the greater)
Output Detail: 2 wire, 4 to 20 mA current loop Maximum Output: 21.5 mA (in high burnout condition) Minimum Output: 3.8 mA (in low burnout condition)
Response Time: 1 sec
Start Up Time: I out < 4 mA during start up
Humidity Range: 10 to 90% RH non condensing
Input Accuracy: ± 0.5 °C
Setup Controls: Pushbutton, Program LED will flash in bursts
Supply Voltage: 10 to 30 Vdc
Sheath Material: N/A
Thermal Effects: 1 uA/°C
Update Rate, Max: 500 ms
Electrical Output: 4 to 20 mA
Supply Power Type: DC
Thermocouple Type: J, K, T, E, R, S, N
Self Heating Effect: 0.2 uA/V
Input Control Signal: -10 to 70 mV
Electrical Connection: Screw Terminal
Programmable Functions: offset, Range, Sensor Burnout Indication, sensor type
Temperature Input Range: K: -200 to 1370 °C; J: -100 to 1200 °C; E: -100 to 1000 °C; N: -180 to 1300 °C; T: -100 to 400 °C; R -10 to 1760 °C; S: -10 to 1760 °C
Storage Temperature, Max: 90 °C
Storage Temperature, Min: -50 °C
Cold Junction Compensation: ±0.05°C/°C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -40 °C
Cold Junction Temperature Accuracy: ±0.5 °C
