Height: 42 mm
Weight: 80 g
Accuracy: ± 0.2 %
Diameter: 62 mm
Mounting: Head-mounted
RTD Type: Pt100, Pt200, Pt500, Pt1000, NI120, CU10
Isolation: 1000 Vrms Continuous
Span, Min: 50°C
Stability: ± 0.15%/ year (Long Term Stability)
Input Type: Thermocouple, RTD, Resistance, Potentiometer, Voltage
Resolution: 2 μA
Output Load: 50 x (Vsupply – 12V) Ω
Sensor Type: Transmitter
Probe Length: 0 mm
Accuracy Note: ± 0.2% of full scale input
Output Detail: 4/20 mA calibrated; 3.8 to 20.5 mA linear Sensor Burnout: Upscale >21 mA, downscale <3.8 mA
Response Time: 1 sec with dampening off
Humidity Range: 20 to 90% RH non-condensing
Setup Controls: 3 pushbuttons on front
Supply Current: 30/150 µA ± 2%
Supply Voltage: 12 to 30 Vdc
Sheath Material: N/A
Housing Material: Plastic, Polycarbonate
Input Resistance: 0 to 2000 Ω
Electrical Output: 4 to 20 mA
Supply Power Note: 12 to 30 Vdc, LED indicator reverse polarity protected 60 Vdc
Supply Power Type: DC
Thermocouple Type: J, K, T, E, R, S, B, N
Input Control Signal: -5 to 60 mV
Electrical Connection: Screw Terminal
Programmable Functions: alarm, °C/°F, Cold Junction, control action, Dampening, Deadband, offset, Range, Sensor Burnout Indication
Wiring/Connector Table: 2- or 3-Wire
Temperature Coefficient: ± 0.01%/°C
Temperature Input Range: 0 to 260 °C
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -20 °C
Cold Junction Compensation: ±2°C
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -20 °C
