Height: 23.6 mm
Weight: 15 g
weight: 15 g
Accuracy: ± 0.1 %
Diameter: 35.6 mm
Bandwidth: 3 dB @ 3Hz
Linearity: ±0.1%
Hysteresis: ±0.1%
Input Type: Thermocouple
Sensor Type: Transmitter
Probe Length: 0 mm
Accuracy Note: ±0.1% FS (includes effects of linearity, hysteresis and repeatability)
Repeatability: ±0.1%
Supply Voltage: 8 to 35 Vdc
Dimensions Note: 23.6 H x 35.6 mm D (0.93 x 1.40") (height includes terminal strip)
Sheath Material: N/A
Electrical Output: 4 to 20 mA
Supply Power Note: 8 to 35 Vdc; 24 Vdc recommended
Supply Power Type: DC
Thermocouple Type: E
Loop Resistance, Max: (Vs-8V)/0.02A
Electrical Connection: Screw Terminal
Temperature Input Range: -18 to 149 °C
Storage Temperature, Max: 125 °C
Storage Temperature, Min: -65 °C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -25 °C
Zero Setting Adjustable Range: ±25%
