Width: 17.5 mm
Height: 17.5 mm
Length: 90 mm
Accuracy: ± 0.04 mV, ± 0.008 mA
Mounting: DIN Rail Mount
Software: Windows PC Software
Approvals: CE, RoHS
Isolation: 500 Vdc
Materials: Polyimide 6.6
Input Type: Thermocouple, RTD, Voltage, Current
Shell Color: Gray
Cable Length: 2.5 mm
Output Value: Process
RTD Accuracy: ±0.1 °C
Relay Output: 250 Vac @ 1 A
Output Detail: Type: 3-wire voltage output with programmable ranges: 0 to 10, 0 to 5, 2 to 10, 1 to 5, and 0 to 1V. Output Drive: 2 mA driving 5 kΩ @ 10V. User Trim: Raise and lower buttons, active for offset when output is at offset and span, trim lock option
Output Signal: Dual form C relay contacts
Response Time: <500 ms
Serial Number: Reverse connection and over-voltage protection, max over voltage current 100 mA
Approvals Note: CE tested to BS EN 61326
Number of Inputs: 3
Relative Humidity: 10 to 95% RH non-condensing
Response Time Note: <500 ms to reach 95% of final value; start up time <3 s
Electrical Connection: Screw Terminal
Thermocouple Accuracy: Type K,J,E,N,T: ± 0.1 %, Type R,S: ± 0.5 °C
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -40 °C
Voltage Measurement Range: -40 to 75 mV
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -20 °C
Temperature Measurement Range: K: 200 to 1370°C, J: -100 to 1200°C, E: -100 to 1000°C, N: -180 to 1300 °C, T:-100 to 400°C, R:-10 to 1760°C, S:-10 to 1760°C,Pt100: -200 to 850°C
