Shutdown: No Shutdown
Topology: Dual
Input Type: Differential
Output Type: Rail-to-Rail
Amplifier Type: Low Voltage Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 8 V/us
THD plus Noise: 0.01 %
Number of Channels: 2 Channel
Supply Voltage - Max: 5 V
Supply Voltage - Min: 1.7 V
Ib - Input Bias Current: 1 pA
Operating Supply Current: 325 uA
Ios - Input Offset Current: 1 pA
Output Current per Channel: 96 mA
Vos - Input Offset Voltage: 5 mV
GBP - Gain Bandwidth Product: 7 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 0.1 pA/sqrt Hz
en - Input Voltage Noise Density: 20 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 90 dB
PSRR - Power Supply Rejection Ratio: 80 dB
