Fall Time: 6 ns
Rise Time: 53 ns
Technology: Si
Unit Weight: 175 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 17 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 54 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 29 ns
Typical Turn-Off Delay Time: 18 ns
Id - Continuous Drain Current: 42 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 55 S
Rds On - Drain-Source Resistance: 13.1 mOhms
Vds - Drain-Source Breakdown Voltage: 80 V
Vgs th - Gate-Source Threshold Voltage: 2 V
