TT Electronics / Optek Technology OPI1280-032 Transistor Output Optocouplers Fiber Optic Isolator 32mm iso dist Side Looker, Transistor
Manufacturer: TT Electronics / Optek Technology Model: OPI1280-032 - Contact
Output Type: NPN Phototransistor
Unit Weight: 6.442 g
Configuration: 1 Channel
Mounting Style: Through Hole
Isolation Voltage: 15000 Vrms
Number of Channels: 1 Channel
If - Forward Current: 20 mA
Vf - Forward Voltage: 2.3 V
Current Transfer Ratio: 10 %
Pd - Power Dissipation: 100 mW
Maximum Collector Current: 360 uA
Current Transfer Ratio - Min: 10 %
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 20 C
Maximum Collector Emitter Voltage: 33 V
