Max working voltage: DC: 0~10kV, AC (rms), 0~7kV, Vpp; 0~20kV(pulse)
Bandwidth: 50MHz.
Noise: > 60dB(1KHz), > 50dB (1Mhz)
Attenuation Ratio: 1:1000
Accuracy: DC± 3% (DC-10KV)
Input impedance: 100MΩ +5%
Input capacitance: 3pF + 0.5pF
Cable length: 2m±0.2m
Temperature coefficient: <200ppm/C
Operating temperature: 0~50C
Volume: 340mm x80
Weight: 250g
