Rated Output (0°C-40°C):
Output Voltage Range: 0-80V; 0-80V
Output Current Range: 0-20A; 0-20A
Power: 1000W
Power Supply: 100V-240Vac; 45Hz-65Hz
Load Regulation±(% of Output+Offset):
CV: ≤0.05% + 20mV
CC: ≤0.05% ± 20mA
linear Regulation±(% of Output+Offset):
CV: ≤0.05% + 20mV
CC: ≤0.05% ± 20mA
Settings Resolution: 10mV/1mA
Readback Resolution: 10mV/1mA
Settings Accuracy:
CV: ≤0.05% ± 20mV
CC: ≤0.05% ± 20mV
Readback Accuracy:
CV: ≤0.05% ± 20mV
CC: ≤0.05% ± 20mV
Noise/Ripple(*):
CV: ≤50mVp-p
CC: ≤20mArms
Temperature Coefficient (0°C-40°C): 100ppm/°C (Voltage); 200ppm/°C (Current)
Readback Temperature Coefficient: 100ppm/°C (Voltage); 200ppm/°C (Current)
Recovery Time (10%~90% rated load): ≤5.0ms
Operation Temperature: 0-40°C
Interface: USB / LAN/RS485
Display: 3.95 inch LCD
Size (W*H*D mm): 215.0 x 88.0 x 453.0
Weight (kg): 5
