Rated Output（0℃-40℃）:
+ Voltage: 0~300V
+ Current: 0~5A
+ Power: 400W
Input Characteristics:
+ Supply Voltage: 100V- 240V
+ Input Frequency: 45- 65Hz
+ Input Fuse: 250V, F10A
Regulation (CV):
+ Load: ≤30mV
+ Line: ≤30mV
Regulation (CC):
+ Load: ≤10mA
+ Line: ≤10mA
Ripple & Noise:
+ Voltage (Vpp): ≤300mVpp
+ Current (rms): ≤30mA
Setting Resolution: 10mV/1mA
Readback Resolution: 10mV/1mA
Setting Accuracy:
+ Voltage: ≤0.05%±200mV
+ Current: ≤0.05%±20mA
Readback Accuracy:
+ Voltage: ≤0.05%±200mV
+ Current: ≤0.05%±20mA
Transient recovery time (10%- 100% rated load): ≤5.0ms
OVP: 0 - 310V
OCP: 0 - 6A
OTP: 85℃
Temperature coefficient of output:
+ Voltage: 100ppm/℃
+ Current: 200ppm/℃
Temperature coefficient of readback value:
+ Voltage: 100ppm/℃
+ Current: 200ppm/℃
Display:
+ Display Type: 2.8-inch Color LCD Display (IPS Panel)
+ Resolution: 240 x 320 pixels
+ Color: 65536 color,TFT
Temperature: Working Temperature：0℃- 40℃; Storage Temperature：-20℃～60℃
Relative Humidity: ≤90%RH; no condensation
Height: 2,000 meters
Cooling: Fan cooling, temperature intelligent speed control
Communication Port: USB, DB9: RS232/RS485(optional), LAN (optional), compatible with the SCPI communication protocol
Dimension: 82mm(W)× 142mm(H)×226mm(D)
Weight: Approx. 1.6kg
