PANASONIC ECQ-E6473JF3 Metallized Polyester Film Capacitors 630VDC 0.047uF 5% MPET L/S=5mm
Manufacturer: PANASONIC Model: ECQ-E6473JF3 - Contact
Width: 6.5 mm (0.256 in)
Height: 18.5 mm (0.728 in)
Length: 12 mm (0.472 in)
Tolerance: 5 %
Dielectric: Polyester
Lead Style: Crimped
Capacitance: 0.047 uF
Unit Weight: 1.700 g
Lead Spacing: 5 mm (0.197 in)
Lead Diameter: 0.6 mm
Number of Pins: 2 Pin
Capacitance - nF: 47 nF
Capacitance - pF: 47000 pF
Termination Style: Radial
Voltage Rating DC: 630 VDC
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
