Fall Time: 104 ns
Rise Time: 83 ns
Technology: Si
Unit Weight: 5.175 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 74 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 260 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 46 ns
Typical Turn-Off Delay Time: 248 ns
Id - Continuous Drain Current: 20.5 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 260 mOhms
Vds - Drain-Source Breakdown Voltage: 500 V
Vgs th - Gate-Source Threshold Voltage: 4 V
