Power (Class 0.2)
1 A AC 0.1 ... 1.2 A
5 A AC 0.5 ... 6.0 A
max. Display Area: 20 kA
Voltage LN (Class 0.2)
57.7 V AC 11.5 ... 70 V
230 V AC 46 ... 276 V
400 V AC 80 ... 480 V
max. Display area: 480 kV
Voltage LL (Class 0,5)
100 V AC 20 ... 120 V
400 V AC 80 ... 480 V
690 V AC 138 ... 830 V
max. Display area: 830 kV
Active Power (Class 0.5): ± 1999.9 W
max. Display range: ± 1999.9 MW
Reactive power (Class 1): ± 1999.9 Var
max. Display range: ± 1999.9 MVar
Apparent power (Class 0.5): 0 ... 1999.9 Va
max. Display range: 0 ... 1999.9 MVA
Active energy (Class 0.5): ± 1999,9Wh
max. Display range: ± 1999.9 MWh
Reactive energy (class 1): ± 1999.9 Varh
max. Display range: ± 1999.9 Mvarh
Apparent energy (Class 0.5): 0 ... 1999 VAh
max. Display range: 0 ... 1999.9 MVAh
Active power factor: -1 .... 1
Frequency: 45 ... 65 Hz
Harmonic distortion / Harmonic Distortion: 0 ... 100%
Harmonics voltage and current up to 51. order: 0 ... 100%
Additional Specifications
Temperature input (optional): 2 x 2-wire PT100
-50 ... 400 ° C / -58 ... 752 ° F
± 0.5% v. MB.
RS485 interface:
Modbus RTU
8N2, 8E1, 8O1, 8N1
address: 1 ... 247
Baud rate: 4800, 9600.19200, 38400, 57600, 115200
Ethernet 10/100 Protocols: TCP, HTTP. FTP
Display: 3.5 "LCD, 320 x 240 pixels
Dimensions: 96 x 96 x 77 mm / 3.7 x 3.7 x 3 in
Panel Cutout: 92.5 x 92.5
Weight: 300 g / 10.5 oz
Protection: Front: IP65, connection side: IP20
Power supply:
85 ... 253 V AC
90 ... 300 V DC
Input: 6 VA
Power loss:
Voltage side: 0.2 VA
Current side: 0.1 VA
Heating time: 5 minutes
Operating conditions: -10 ... 55 ° C / 0 ... 95% rh
Operating position Each
Overload Voltage: 2 x Un (5 seconds),
current: 50 A (1 second).
Electromagnetic compatibility
EN 61000-6-2
EN 61000-6-4
Housing insulation: Double to EN61010-1
Pollution degree: 2
Insulation Category: III
