PCE-C-R19LFC-H9 Force Sensor 5-500 kg

  • Manufacturer:PCE
    Model: C-R19LFC-H9
    Guarantee: 12 Month
    • Request a Quotation Request a Quotation
  • Contact
    • Add to Cart
    • Buy
  • Contact us for the best price

    Myanmar: 09 266993007

    Email: info@emin.com.mm

Manufacturer: PCE-ANH

Model : PCE-C-R19LFC-H9

Warranty : 12 months


Specification

Rated load / force F.S.:

5 / 10 / 20 / 50 / 100 / 200 / 500 kg

50 / 100 / 200 / 500 / 1000 / 2000 / 5000 N

! Rated load / force selectable !

Limit load / force: 120 %

Breaking load / force: 150 %

Rated output: 1.0 – 1.5 mV/V

Operating range of supply voltage: 2.5 V – 5 V

Maximum supply voltage: 5 V

Deviations of the zero signal: ± 2 % F.S.

Linearity deviation: 0.5 % F.S.

Reverse voltage (hysteresis): 0.5 % F.S.

Repeatability: 0.5 % F.S.

Stress creep (30 min): 0.1 % F.S.

Input resistance: 350 ± 10 Ω

Output resistance: 350 ± 3 Ω

Insulation resistance: ≥5000 MΩ / 100 VDC

Nominal range of ambient temperature: -10 … 60 °C / 14 ... 140 °F

Service temperature range: -20 … 80 °C / -4 ... 176 °F

Temperature coefficient of characteristic value: 0.1 % F.S. / 10 °C

Temperature coefficient of zero point: 0.1 % F.S. / 10 °C

Sensor cable: Ø 2 x 3 m / (ends open)

Cable assignment:

EXC+ = red

EXC- = black

SIG+ = green

SIG- =  white

GND = yellow

Material / measuring body: stainless steel

Protection: IP65
