IMAGE & SENSITIVITY
Sensor Type: CMOS, Back Side Illuminated (BSI) with Global Shutter
Maximum Resolution: 1280 x 832 Binned 640 x 384
CAR Increments: 256 x 32 Binned 128 x 64
Pixel Size (μm): 18.5 Binned 37.0
Sensor Size (mm): 23.7 x 15.4
Bit Depth (ADCs): 12 bit
CONNECTIVITY & SIGNALS
Ethernet: Gigabit and 10Gb Ethernet (standard)
Timecode: IRIG-B Modulated and Un-modulated
Rear Port Descriptions:
Ethernet - Fischer 8-pin
Power 20-28V - Fischer 6-pin
RDIO Range data + 2 Programmable I/O - Fischer 8-pin
3 Dedicated BNCs for Trigger, Timecode-in and SDI Video
1 Dedicated BNC for Programmable I/O
Programmable I/O Signals: (3 ports) for Strobe, Fsync, Ready, Timecode Out, MultiStrobe, Auto Trigger (+mode 2), SW Trigger, Recording, Event In, Memory Gate In, Pretrigger In, Auxtrigger In, Range Data Corrp. Assign and define signals in PCC
Hardware Trigger: TTL (falling or rising edge), or High-Voltage (falling or rising edge). Dedicated BNC
Software Trigger: Trigger button; via Ethernet; via Image-based auto trigger (IBAT), via SDK command or telnet
Synchronization: External Sync (5V TTL) via Fsync or IRIG-B Timecode
Recording Features: External frame rate control, burst mode, continuous recording, multi-partitions, frame straddling
Video Output: 3G-SDI via BNC (rear), Din and HDMI (front)
Accessory Power: 4-pin Hirose (front) for 12V monitors up to 1 Amp
MEMORY & STORAGE
RAM Buffer: 16GB, 32GB, 64GB (KT810); 32GB, 64GB, 128GB
Capture Duration: 32GB 1.7s; 64GB 3.4s; 128G 6.8s
Multi-Cine: Up-to 63 Partitions
Non-Volatile Media:
CF Express type B
Approved cards at launch: Exascend 1TB Esssential
Series and Pro; Wise Advanced 1TB
Media Transfer Rates: 275 MB/s, Full 32GB RAM save time = 2 minutes
FRAME RATES & EXPOSURE
Top FPS at Max Resolution: 12,090
Maximum FPS: : 578,940 std, 708,330 w/ FAST option* KT1210-E225: 225,000
Minimum FPS: 100
Frame Timer Clock: 110 MHz
Minimum Exposure: 1.06 μs standard; 190 ns with FAST Option*
PIV Features: Shutter-off mode with a straddle time of 246 ns (effective frame pair frequency of 4.06 MHz for frame straddling PIV)
Exposure Features: Burst Mode; EDR (Extreme Dynamic Range); Auto-Exposure, Overexposure indication over video and in PCC
POWER
AC Power: 100-240 VAC, 160W power supply included
Voltage Range: 20-28V
Power Consumption: 90W typical
Battery Options: Works with 24V battery sources only, input through primary power port
