Color: Gray
Width: 8.2 mm
Height: 57.6 mm
Length: 76.7 mm
Current Rating: 41 A
Mounting Style: DIN Rail (NS 35/7.5, NS 35/15)
Number of Rows: 1 Row
Voltage Rating: 1 kV
Wire Gauge Max: 8 AWG
Wire Gauge Min: 16 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 16 AWG to 8 AWG
Connection Method: Push-In
Flammability Rating: UL 94 V-0
Number of Positions: 3 Position
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 60 C
