Cutting angle:
- At 90°
Round: 300mm
Square: 290 x 290mm
Rectangular: 360 x 295mm
- At +45°
Round: 245mm
Square: 245 x 245mm
Rectangular: 245 x 250mm
Main motor: 400 V / 50 Hz / 2.2 kW
Pump motor: 400 V / 50 Hz / 0.05 kW
Hydraulic motor unit: 400 V / 50 Hz / 0.55 kW
Servo motor of the feed: 1.2 kW
Feed rate of material: 1.6 / 2.5 / 3 m/min.
Saw blade speed: 15-90 m/min.
Working height of vice: 850 mm
Hydraulic system oil: cca 26 l (ISO 6743/4-HM, DIN 51 524 part 2-HLP
Coolant tank: cca 35 l
Machine dimensions (min.): 2100 x 1700 x 1600 mm
Machine dimensions (max.): 2700 x 2215 x 1780 mm
Machine weight: 1270 kg
