Output Voltage( DC Max): 800V DC
Output Voltage(AC Max): 1600Vp-p
DC Current(Max): 65mA
AC Current(Max): 130mAp-p
Output Power(Max): 52VA
Frequency response (Bandwidth): 200kHz/800Vp-p
Slew Rate: 1000V/μs
Output impedance: 10Ω
Protect resistor: 5kΩ/60watt
Safe Loading: ≧12.5kΩ/1600Vp-p
Input Voltage upper limit: -5V~+5V(Max -10V~+10V)
AMPL: 200
OFFEST: ± 800V
Monitor: 200:1
Output protection:
1. Output dedicated FUSE
2. Protection SW (switch)
3. High-speed overload protection circuit
Weight: 5.4kg
size: 320*260*150g
