Applications
- Pharmaceutical WFI, PW performance verification
- Medical device cleanliness testing
- Parenteral sampling
- Detect abrasive particles
- Continual process improvements
- USP 788-1788 compliance with the SLS sampler family
Specifications
- Size range: 2 – 125 µm
- Flow rate: 70 ± 10% ml/min
- Sample volume: Volumetric 70 ml/min (100%)
- Size channels: User adjustable from 1 to 15
- Resolution Less than 10% at 10 µm
- Maximum concentration: 10,000 particles/ml
- Sample temperature: 50 – 122 °F (0 – 50 °C)
- Zero count: < 15 counts/liter
- Pressure range: 0 - 100 psi
- Laser source: Laser diode
- Wetted surface materials: Fused silica, black quartz, Kalrez® and Kel-F®
- Liquid connections: 3 mm flare or 1/4-inch Flaretek®
- Dimensions (l, w, h): 32.4 x 10.8 x 11 .4 cm
- Weight: 6.1 lb (2.8 kg)
- Electrical rating: 100 - 240 V, 50/60 Hz, 0.75 A
- Communication modes: 5-wire, RS-485, DE9 connectors, PMS serial communications protocol, 10/100BaseT Ethernet, PMS
Ethernet Protocol, Modbus TCP
- Calibration fluid: DI water
- Calibration: Materials used are traceable to U.S. National Institute of Standards and Technology (NIST) and/or
- Japanese Institute of Standards (JIS)
- Environment: Temperature: 50 – 95 °F (10 – 35 ºC); Humidity: non-condensing
