TT Electronics / Power Partners PAA25-14 AC-DC Power Modules 25W/24V AC/DC ENCAPSULATED
Manufacturer: TT Electronics / Power Partners Model: PAA25-14 - Contact
Width: 27.5 mm
Height: 23.5 mm
Length: 52.5 mm
Industry: Industrial
Approvals: EN, IEC, TUV, UL
Dimensions: 52.5 mm x 27.5 mm x 23.5 mm
Output Power: 25 W
Input Voltage: 90 VAC to 305 VAC, 127 VDC to 430 VDC
Mounting Style: Through Hole
Input Frequency: 47 Hz to 440 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 1.042 A
Output Voltage-Channel 1: 24 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 40 C
