Output Power : 5kW
INPUT:
Input Voltage : 1Ø 2W+G 187-264 VAC
Input Current : 30A
Input Frequency : 47 Hz-63 Hz
Power Factor : ≥ 0.99 at max. power
OUTPUT:
Voltage : 0~40V
Current : 0~125A
Voltage Ripple (RMS)*1 : ≤0.1% F.S.
Voltage Ripple*1 (peak to peak) : ≤1.5% F.S.
Voltage Line Regulation : ≤0.1% F.S.
Voltage Load Regulation*2 : ≤ 0.1% F.S.
Current Ripple (RMS) : ≤ 0.08% F.S.
Current Line Regulation : ≤0.05% F.S.
Current Load Regulation : ≤0.15% F.S.
Slew Rate*3:
Rise Time : ≤ 8ms
Fall Time (Full Load) : ≤ 3ms
Fall Time (No Load):
Transient Response*4 : ≤ 5ms
Programming & Measurement:
Voltage Programming Accuracy : ≤ 0.08% F.S. +0.01V
Voltage Measurement Accuracy : ≤ 0.08% F.S. +0.01V
Voltage Resolution 10mV 100mV:
Current Programming Accuracy : ≤ 0.2% F.S. +0.1A
Current Measurement Accuracy : ≤ 0.2% F.S. +0.1A
Current Resolution 0.1A 10mA:
Power Programming Accuracy : ≤ 0.3% F.S.
Power Measurement Accuracy : ≤ 0.3% F.S.
Power Resolution 0.01kW:
General Specs:
Efficiency*5: ≥ 88% at max.power
Interfaces: Standard: RS-232, RS-485, Ethernet, USB, Analog Option: GPIB
Analog Input Control (V & I ): 0-5V, 4-20mA, Accuracy : 1% F.S. (at output rated voltage & current ≥ 5%)
Analog Output Monitor (V & I ) : 0-5V, Accuracy : 2% F.S.
Remote Sensing : ≤ 5V
Operating Temperature : 0℃ ~ 40℃
Storage Temperature: -20℃ ~ 70℃
Protections : OVP、OCP、OPP、OTP、Vin OV、LDC OV、Remote Error、FAN, Error
OVP Range : 0 - 110% F.S.
OCP Range : 0 - 110% F.S.
OPP Range : 0 - 110% F.S.
Dimension (HxWxD) : 132 x 442 x 731.5 mm / 5.2 x 17.4 x 28.8 inch
Weight*6: approx. 20.7kg / 45.7 lbs
