INPUT
Phase: 3Ø / 4 Wire + G
Voltage*1: 220/380Vac ±15% (option: 120/208Vac, 277/480Vac, 200Vac or 400Vac)
Frequency: 50Hz ± 3Hz or 60Hz ± 3Hz
Max. Current*2: 23A
Power Factor: ≥0.9Max. Power
OUTPUT
Power (VA): 10kVA
Phase: 1Ø / 2 Wire + G
Voltage Ranges: Low(V): 5V-150.0V（L-N）; High(V): 10V-300.0V（L-N）
Voltage Resolution: 0.1V
Voltage Accuracy: 0.2% F.S.+4counts
Frequency Range *3: Standard : 45-65Hz Option : 400Hz
Frequency Resolution: 0.1Hz
Frequency Accuracy: ±0.1% F.S
Max. Current: Low(A): 83.3A; High(A): 41.7A
Line Regulation: ≦ 1%
Load Regulation: ≦ 1% (Resistive Load)
Total Harmonic Distortion*3: ≦ 2% (Resistive Load)
Response Time: ≦ 2ms
MEASUREMENT
Voltage Range: 0V-600.0V
Voltage Resolution: 0.1V
Voltage Accuracy: 0.2% F.S.+4counts
Frequency Range: 0-999.9Hz
Frequency Resolution: 0.1Hz
Frequency Accuracy: ±0.1% F.S.
Current Range(RMS): 0 - 9999A
Current Resolution(RMS): 0.01A( ＜ 100A) / 0.1A( ≧ 100A)
Current Accuracy(RMS): 0.2% F.S.+4counts
Power Range: 0-75kW
Power Resolution: 0.01kW( < 10kW) / 0.1kW( ≥ 10kW)
Power Accuracy: 0.3% F.S.+4 counts
GENERAL
Efficiency: ≥90 % at Max. Power
HMI: Digital LED Display
Opertional Temperature: 0℃ ~45℃
Humidity: 0~90% ( Non condensing )
Altitude: < 1,500m
Dimensions (H x W x D) *4: 1045 x 600 x 850 mm (Including wheel) / 41.1 x 23.6 x 33.5 inch (Including wheel)
Weight *4: 230kg/507.2lbs
*1 Please contact us for other input voltage specifications.
*2 The max. current is based on rated input voltage of 220V.
*3 For type A: 45~500Hz, please contact us for output power characteristic curve.
*4 Dimensions and weight are for input voltage 220V. Please contact us for dimensions and weight for other input voltage.
* All specifications are subject to change without notice. The specifications are tested at ambient temperature of 25°C ± 5°C
