Max Power: 250 W
Max Current: 50 A
Operation Voltage: 80 V
Min. Operating Voltage: 1.0V at 50A
Protection: Over Power Protection (OPP); Over Current Protection (OCP); Over Voltage Protection (OVP); Over Temp. Protection (OTP)
CC MODE Range: 0~5.04~50.4 A
CR MODE Range: 0.016~1.6~96000Ω
CV MODE Range: 0~8.1~81 V
CP MODE Range: 0~25.02~250.2 W
Dynamic Operation: 10 μS to 9.999 Sec
Measurement:
- 5 1/2 DVM: 0~8.1~81 V
- 5 1/2 DAM: 0~5.04~50.4 A
Surge Test: 0~50A
Battery Discharge Test: 0~81V
Load ON Voltage: 0.1~25V
Load OFF Voltage: 0~25V
Imonitor (non-Isolated): 5.04 A/V
Typical Short Resistance: 0.018 Ω
Max. short Current: 50A
Interface: USB / RS232
Power Comsumption: 40VA
Dimension(HxWxD): 205 x 123 x 477mm
Weight: 5.3Kg
