Max Power: 350 W
Max Current: 15 A
Operation Voltage: 500 V
Min. Operating Voltage: 6V at 15A
Protection: Over Power Protection (OPP); Over Current Protection (OCP); Over Voltage Protection (OVP); Over Temp. Protection (OTP)
CC MODE Range: 0~1.5~15 A
CR MODE Range: 0.4~40~2400000Ω
CV MODE Range: 0~60~500 V
CP MODE Range: 0~35.04~350.4 W
Dynamic Operation: 10 μS to 9.999 Sec
Measurement:
- 5 1/2 DVM: 0~60~500 V
- 5 1/2 DAM: 0~1.5~15 A
Surge Test: 0~15A
Battery Discharge Test: 0~500V
Load ON Voltage: 0.4~100V
Load OFF Voltage: 0~100V
Imonitor (non-Isolated): 1.5 A/V
Typical Short Resistance: 0.367Ω
Max. short Current: 15A
Interface: USB / RS232
Power Comsumption: 40VA
Dimension(HxWxD): 205 x 123 x 477mm
Weight: 5.3Kg
