Max Power: 700 W
Max Current: 140 A
Operation Voltage: 80 V
Min. Operating Voltage: 0.9V at 140A
Protection: Over Power Protection (OPP); Over Current Protection (OCP); Over Voltage Protection (OVP); Over Temp. Protection (OTP)
CC MODE Range: 0~14.04~140.4 A
CR MODE Range: 0.0057~0.57~34200 Ω
CV MODE Range: 0∼8.1∼81 V
CP MODE Range: 0~70.02~700.2 W
Dynamic Operation: 10 μS to 9.999 Sec
Measurement:
- 5 1/2 DVM: 0∼8.1∼81 V
- 5 1/2 DAM: 0~14.04~140.4 A
Surge Test: 0~140A
Battery Discharge Test: 0~81V
Load ON Voltage: 0.1~25V
Load OFF Voltage: 0~25V
Imonitor (non-Isolated): 14.04 A/V
Typical Short Resistance: 0.0053Ω
Max. short Current: 140A
Interface: USB / RS232
Power Comsumption: 60VA
Dimension(HxWxD): 205 x 231 x 480mm
Weight: 10.3Kg
