Power: 10800W
Current: 0~720A
Voltage: 0~60V
Min.Operation Voltage: 0.6V@720A
CC mode:
Range: 0~72A/720A
Resolution: 1.2mA/12mA
Accuracy: ±0.1%
CR mode:
Range: 0.00138~0.083~5KΩ
Resolution: 0.0014mΩ/0.2mS
Accuracy: ±0.2%
CV mode:
Range: 6V/60V
Resolution: 0.1mV/1mV
Accuracy: ±0.05%
CP mode:
Range: 1080W/10800W
Resolution: 18mW/180mW
Accuracy: ±0.5%
Measurement mode (Load):
Voltage: 0 ~ 6V/60V, ±0.025%
Current : 0 ~ 72A/720A, ±0.1%
Power : 0 ~ 10800W, ±0.125%
Protections:
Over voltage: 105%
Over current: 105%
Over power: 105%
Over temp.: Yes
Short circuit current: 720A
Dimension (HxWxD): 1556 x 596 x 600 mm
Weight: 208.6 kg
Input: 115/230Vac, 50/60Hz
Optional interface: GPIB, RS232, USB, LAN
