Power: 10KW
Current: 0~150A/0~1500A
Voltage: 0~60V
Min.Operation Voltage: 0.1V at 150A/0.7V at 1500A
Protections:
Over Power Protection (OPP): 105%
Over Current Protection (OCP): 104%
Over Voltage Protection (OVP): 105%
Over Temp Protection (OTP): Yes
CC mode:
Range: 0~150A/0~1500A
Resolution: 2.4mA/24mA
Accuracy: ±0.1%
CR mode:
Range: 2400-0.04ohm/0.04-0.0007ohm
Resolution: 555.5uS/0.7uΩ
Accuracy: ±0.2%
CV mode:
Range: 60V
Resolution: 1mV
Accuracy: ±0.05%
CP mode:
Range: 1000W/10000W
Resolution: 16mW/160mW
Accuracy: ±0.5%
Measurement mode (Load):
Voltage: 0 ~ 6V/6~60V, ±0.025%
Current : 0 ~ 150A/150~1500A, ±0.1%
Power : 1500W/15000W, ±0.125%
Short circuit current: 1500A
Dimension (HxWxD): 573 x 647 x 766 mm
Weight: 130 kg
Input: 115/230Vac, 50/60Hz
Optional interface: GPIB, RS232, USB, LAN
