Power: 10KW
Current: 0 ~ 70A; 0 ~ 700A
Voltage: 0 ~ 600V
Min. Operating Voltage: 10V at 700A
Protections: Over Power Protection (OPP); Over Current Protection (OCP); Over Voltage Protection (OVP); Over Temp Protection (OTP)
Constant Current Mode Range: 70A; 700A
Constant Resistance Mode Range: 51427.2Ω~0.85712Ω; 0.85712Ω~0.014304Ω
Constant Voltage Mode Range: 600V
Constant Power Mode Range: 1000W; 10000W
Constant Voltage Mode + Constant Current Mode Range: 600V; 700A
Constant Voltage Mode + Constant Power Mode Range: 600V; 10000W
Surge & Normal current: 0~700A
Dynamic Mode:
- Timing: 0.010~9.999 / 99.99 / 999.9 / 9999mS
- Current: 0~70A; 70~700A
Measurement
- Voltage Read Back Range (5 Digital): 0~60V; 60~600V
- Current Read Back Range (5 Digital): 0~70A; 70~700A
- Power Read Back Range: 10000W
Typical Short Resistance: 0.0143Ω
Maximum Short Current: 700A
Load ON Voltage: 0.4 ~ 100V
Load OFF Voltage: 0 ~ 100V
Power Consumption: 750VA
Dimension (HxWxD): 572x444x763mm
Weight: 84.8 kg
Temperature: 0~40℃
