Power: 50KW
Current: 0~25A/0~250A
Voltage: 0~1250V
Protections:
Over Power Protection (OPP): 105%
Over Current Protection (OCP): 104%
Over Voltage Protection (OVP): 104%
Over Temp Protection (OTP): Yes
CC mode:
Range: 0~25A/0~250A
Resolution: 0.42mA/4.2mA
Accuracy: ±(0.1% of Setting + 0.2% of Range)
CR mode:
Range: 5712Ω ~ 4.76Ω/4.76Ω ~ 0.24Ω
Resolution: 3.5014μS/0.08mΩ
Accuracy: ±0.2%
CV modes:
Range: 1250V
Resolution: 20mV
Accuracy: ±0.05%
CP mode:
Range: 5000W/50000W
Resolution: 84mW/850mW
Accuracy: ±0.5%
Measurement mode (Load):
Voltage: 0 ~ 125V/125~1250V, ±0.025%
Current : 0 ~ 26.25A/26.25~250A, ±0.1%
Power : 10000W/50000W, ±0.125%
Short circuit current: 250A
Dimension (HxWxD): 1353 x 853 x 766mm
Weight: 510 kg
Optional interface: GPIB, RS284, USB, LAN
