Electrode quantity: 7
Effective length: 360
Total length: 490
Gas connector quantity: 1
Slider quantity: 2
Ion generation method: Corona discharge method
High voltage working mode: AC-CO
INPUT VOLTAGE: 24～36 V DC ±10％
Working current: MAX 300mA
power consumption: MAX 6W
Output voltage: 12kV VPP
frequency: 240-270Hz
account for: 30-70%
Electrode material: Tungsten (standard); Si (optional)
Discharge component: replaceable
Ionic balance * 1: ±30V
work distance: 100-1500mm
Total length that can be processed: 370-3010mm
Remote control: Remote start stop
Output when abnormal: Low level contact signal
Communication protocol * 2: RS-485（MODBUS RTU）
Gas supply pressure range: 0.1-0.5Mpa (CDA, no condensation)
Gas joint thread: PT1/8
Tracheal size: Φ 6 (optional Φ 8)
major function: Status indication, abnormal protection, cleaning reminder, remote control
Ozone concentration: ≤0.05ppm
operation temperature: 0～40℃
Working humidity: 35% to 85% RH (no condensation)
*1 The following adjustment test values
Test distance 300mm, test pressure 0.2MPa, test temperature: (23 ± 3) ℃, test humidity: (50 ± 5)%
*2 Optional functions
