Gain: 27 dB
Technology: GaAs
Unit Weight: 303.571 mg
Mounting Style: SMD/SMT
Test Frequency: 8 GHz
Input Return Loss: 13 dB
NF - Noise Figure: 1.5 dB
Number of Channels: 1 Channel
Operating Frequency: 5 GHz to 11 GHz
Pd - Power Dissipation: 380 mW
Operating Supply Current: 45 mA
Operating Supply Voltage: 4 V
P1dB - Compression Point: 13 dBm
OIP3 - Third Order Intercept: 23 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
