Radiall R161220000 Connectors N / STRAIGHT JACK CLAMP TYPE CABLE 10+11/50+75 S+D

Name: Radiall R161220000 Connectors N / STRAIGHT JACK CLAMP TYPE CABLE 10+11/50+75 S+D
Brand: Radiall

ModelR161220000

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Gender: Jack (Socket)

Polarity: Standard

Impedance: 50 Ohms

RF Series: N Type

Body Style: Screw On

Cable Type: RG-11, 144, 165, 213, 214, 216, 225, 393, KX13, KX4, KX8

Body Finish: Bright Bronze Radiall

Orientation: Straight

Unit Weight: 49.790 g

REACH - SVHC: Details

Body Material: Brass

Mating Cycles: 500

Mounting Style: Cable Mount / Free Hanging

Voltage Rating: 1.4 kV

Contact Plating: Gold

Contact Material: Beryllium Copper

Maximum Frequency: 11 GHz

Termination Style: Clamp

Insulation Resistance: 5 GOhms

Maximum Operating Temperature: + 155 C

Minimum Operating Temperature: - 55 C
