Metrological parameters:
E1 Calibration Range : -
E2 Calibration Range : 5 kg
F1 Calibration Range: 1 – 5 kg
F2 Calibration Range : 500 g – 5 kg
M1 Calibration Range: 200 g – 5 kg
M2 Calibration Range : 10 g – 5 kg
Maximum capacity [Max] : 5100 g
Readability [d]: 1 mg
Standard repeatability [5% Max] : 0.8 mg
Standard repeatability [Max] : 1 mg
Permissible repeatability : 2 mg
Eccentricity (tested load): 1d / 5 mm
Electric compensation range -: 0 – +5100 g
Stabilization time : 10 s
Adjustment: internal
Physical parameters:
Display : 10″ graphic colour touchscreen
Weighing pan dimensions : ø100 mm
Weighing device dimensions : 385×195×210 mm
Controling device dimensions : 249×170×72 mm
Anti-draft chamber dimensions : 560×340×455 mm
Packaging dimensions : 945×820×1260 mm
Net weight : 16 kg
Gross weight : 24.5 kg
Communication interface:
Communication interface : 2×USB-A, USB-C, HDMI, Ethernet, Wi-Fi,Hotspot
Environmental conditions:
Operating temperature : +15 – +30 °C
Operating temperature change rate: ±0.5 °C / 12 h (±0.3 °C / 4 h)
Relative humidity : 40% – 60%
Relative humidity change rate : ±3% / 4 h
