Width: 9.8 mm (0.386 in)
Height: 12.5 mm (0.492 in)
Length: 19.5 mm (0.768 in)
Industry: Medical
Compliance: CAN/CSA; EAC; IEC; RoHS; UL
Efficiency: 84%
Unit Weight: 4.300 g
Output Power: 2 W
Input Voltage: 13.5 V to 16.5 V
Mounting Style: Through Hole
Isolation Voltage: 8 kV
Number of Outputs: 1 Output
Input Voltage - Max: 16.5 V
Input Voltage - Min: 13.5 V
Input Voltage, Nominal: 15 V
Output Current-Channel 1: 400 mA
Output Voltage-Channel 1: 5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
