Width: 27.4 mm
Height: 23 mm
Length: 52.5 mm
Industry: Industrial
Approvals: EN60335-1, IEC60335-1, IEC60950-1, UL60950-1, UL62368-1
Compliance: CAN/CSA; CE; EAC; ERP; IEC; RoHS; UL
Efficiency: 84%
Unit Weight: 65 g
Output Power: 10 W
Input Voltage: 85 VAC to 305 VAC, 120 VDC to 430 VDC
Mounting Style: Through Hole
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Input Voltage - Max: 305 VAC
Input Voltage - Min: 85 VAC
Open Frame/Enclosed: Enclosed
Standard Packaging Size: 2 x 1
Output Current-Channel 1: 840 mA
Output Voltage-Channel 1: 12 VDC
Maximum Operating Temperature: + 65 C
Minimum Operating Temperature: - 40 C
