Width: 7.05 mm (0.278 in)
Height: 10.2 mm (0.402 in)
Length: 19.65 mm (0.774 in)
Industry: Industrial
Compliance: EAC; IEC; REACH; RoHS; UL
Efficiency: 88%
Unit Weight: 2.800 g
Output Power: 2 W
Input Voltage: 4.5 V to 5.5 V
Mounting Style: Through Hole
Isolation Voltage: 4 kV
Number of Outputs: 2 Output
Input Voltage - Max: 5.5 V
Input Voltage - Min: 4.5 V
Input Voltage, Nominal: 5 V
Output Current-Channel 1: 66 mA
Output Current-Channel 2: 66 mA
Output Voltage-Channel 1: 15 V
Output Voltage-Channel 2: - 15 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
