Width: 7.05 mm (0.278 in)
Height: 10.2 mm (0.402 in)
Length: 19.65 mm (0.774 in)
Industry: Industrial
Compliance: CSA; EAC; IEC; REACH; RoHS; UL
Efficiency: 86%
Unit Weight: 2.800 g
Output Power: 2 W
Input Voltage: 10.8 V to 13.2 V
Mounting Style: Through Hole
Isolation Voltage: 4 kV
Number of Outputs: 2 Output
Input Voltage - Max: 13.2 V
Input Voltage - Min: 10.8 V
Input Voltage, Nominal: 12 V
Output Current-Channel 1: 50 mA
Output Current-Channel 2: 200 mA
Output Current-Channel 3: - 80 mA
Output Current-Channel 4: 80 mA
Output Voltage-Channel 1: 20 V
Output Voltage-Channel 2: - 5 V
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 40 C
