Width: 20.3 mm (0.799 in)
Height: 10.6 mm (0.417 in)
Length: 31.8 mm (1.252 in)
Industry: Industrial
Dimensions: 31.8 mm x 20.3 mm x 10.6 mm
Output Power: 10 W
Input Voltage: +/- 36 VDC to +/- 110 VDC
Mounting Style: Through Hole
Isolation Voltage: 3 kV
Number of Outputs: 2 Output
Input Voltage - Max: 160 V
Input Voltage - Min: 36 V
Input Voltage, Nominal: 110 V
Output Current-Channel 1: 333 mA
Output Current-Channel 2: 333 mA
Output Voltage-Channel 1: 15 V
Output Voltage-Channel 2: - 15 V
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
