Width: 25.4 mm (1 in)
Height: 16.5 mm (0.65 in)
Length: 31.4 mm (1.236 in)
Industry: Industrial
Compliance: EAC; REACH; RoHS; UL
Efficiency: 85%
Unit Weight: 23 g
Output Power: 10 W
Input Voltage: 18 V to 75 V
Mounting Style: Through Hole
Isolation Voltage: 1.6 kV
Number of Outputs: 1 Output
Input Voltage - Max: 75 V
Input Voltage - Min: 18 V
Input Voltage, Nominal: 48 V
Standard Packaging Size: 1 x 1
Output Current-Channel 1: 3 A
Output Voltage-Channel 1: 3.3 V
Maximum Operating Temperature: + 78 C
Minimum Operating Temperature: - 40 C
