RIGOL DP932A Programmable linear DC power supply (3CH; 210W)

Number of Channels: 3

Total power: 210W

DC Output (0℃~40℃):

+ Voltage/Current :

  CH1, CH2: 0 to 32 V/0 to 3 A

CH3: 0 to 6 V/0 to 3 A

+ OVP/OCP

CH1, CH2: 1 mV to 35.2 V/1 mA to 3.3 A

CH3: 1 mV to 6.6 V/1 mA to 3.3 A

Load Regulation Rate:

+ Voltage[2]:  <0.01%+2 mV

+ Current:  <0.01%+250 μA

Line Regulation Rate:

+ Voltage[2]:  <0.01%+2 mV

+ Current:  <0.01%+250 μA

Output ripple and noise (20 Hz to 20 MHz):

+ Normal mode voltage:  <350 μVrms/2 mVpp

+ Normal mode current:  <2 mArms

Accuracy 12 months (25ºC±5ºC):

+ Programming

CH1, CH2: Voltage: 0.05%+10 mV; Current: 0.2%+5 mA

CH3: Voltage: 0.1%+5 mV; Current: 0.2%+5 mA

+ Readback:

CH1, CH2: Voltage: 0.05%+10 mV; Current: 0.15%+5 mA

CH3: Voltage: 0.1%+5 mV; Current: 0.15%+5 mA

Resolution( Standard):

+ Programming: Voltage:  1 mV; Current: 1 mA

+ Readback: Voltage:  0.1 mV; Current: 0.1 mA

+ Display: Voltage: 1 mV; Current: 1 mA

Command processing time: <10 ms

OVP/OCP Accuracy:

+ OVP accuracy, ± (% of output + offset): 0.2%+20 mV

+ OCP accuracy, ± (% of output + offset): 0.5%+20 mA

Mechanical characteristics:

+ Dimension: 239 mm (W) x 157 mm (H) x 419 mm (D)

+ Weight: 9.15 kg

+ Rack mount kit: Three rack-units (3U), 1/2-rack form factor
