Width: 1.7 mm
Height: 0.77 mm
Length: 2 mm
Fall Time: 11 ns
Rise Time: 11 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 800 mW
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 8 ns
Typical Turn-Off Delay Time: 20 ns
Id - Continuous Drain Current: 1 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 250 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
