Frequency Range: DC – 26.5 GHz
VNA End: NMD 3.5mm female
DUT End: NMD 3.5mm male
VSWR: 1.25
Insertion Loss: < 1.8 dB
Phase Stability: < ±2°
Amplitude Stability: < ± 0.05 dB
Shielding Effectivity: > 100 dB
Cruch Resistance: > 130 kgf/cm
Length: 97 cm (38.2 inch)
Impedance: 50 Ω
Outer Diameter: 15.2 mm
Minimum Bend Radius: 50 mm
Connector Materials:
Body: Stainless steel, Passivated
Center conductor: Au-plated beryllium Copper
Cable Materials
Center conductor: Au-plated copper
Dielectric: PTFE
Inner braid: Ag-plated copper braid
Outer conductor: Ag-plated copper tape
