Connector Type: Jack
Current Rating: 5 A
Mounting Angle: Right Angle
Mounting Style: Through Hole
Voltage Rating: 24 VDC
Contact Plating: Nickel
Contact Material: Copper
Housing Material: Brass
Termination Style: Solder
Flammability Rating: UL 94 V-0
Insulation Resistance: 100 MOhms
Inside Contact Diameter: 2 mm
Outside Contact Diameter: 5.5 mm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 25 C
